Planning a kitchen layout means deciding where your sink, stove, cabinets, and appliances go before a single unit is ordered — and getting it right saves you from expensive changes later.
By Free Room Planner Team · Last updated: June 2026Most kitchen mistakes happen before the first delivery van arrives. The layout decisions you make now — not the cabinet finish or worktop material — determine whether your kitchen works well every single day. This guide walks you through the full planning process, from measuring your room to sharing a finished floor plan with your fitter. And you can do it all right now, free, with no sign-up and no download.
Start planning your kitchen layout now — free, no sign-up, no download required. Open Free Room Planner in your browser and draw your kitchen to scale in minutes.
TL;DR
- Layout determines function. Choose your configuration before you think about finishes.
- Five main kitchen layouts: galley, L-shape, U-shape, island, and single-wall.
- Measure your room first — doors, windows, utility points, ceiling height.
- The work triangle (sink, stove, fridge) is a useful guide, not a strict rule.
- Use a free browser-based kitchen floor plan tool to draw, adjust, and export your layout.
- Share the finished plan with your fitter to reduce miscommunication and get accurate quotes.
Why Your Kitchen Layout Matters More Than Your Cabinet Choice
A beautiful kitchen with a poor layout is frustrating to use every day. A modest kitchen with a well-thought-out layout feels effortless. Layout is the skeleton — everything else hangs off it.
The cost of getting it wrong
Changing cabinet positions after installation can cost hundreds to thousands in labour. Moving a plumbing stack or relocating an extractor duct is even more expensive. Getting the layout right on paper — or on screen — before anyone picks up a drill is the single biggest money-saving step in any kitchen renovation.
For a broader look at the full renovation process, see the guide to how to plan a kitchen renovation.
What a good layout actually delivers
A well-planned kitchen gives you smooth traffic flow, logical storage placement, and safe clearances around appliances. It means two people can cook at the same time without colliding. It means the dishwasher is next to the sink, not across the room. Small decisions on a floor plan translate directly into daily convenience.
The Five Classic Kitchen Layout Types
Choose your configuration based on your room shape, how many people cook at once, and how the kitchen connects to the rest of the home.
Galley kitchen layout
Two parallel runs of cabinets face each other with a central aisle. It's the most space-efficient layout for a narrow room and is a favourite in flats and smaller homes. The trade-off: it can feel enclosed and doesn't suit open-plan living well.
L-shape kitchen layout
Cabinets run along two adjoining walls, leaving the rest of the room open. It's versatile, works well in medium-sized rooms, and allows for a dining area in the same space. The corner junction needs careful planning to avoid dead storage.
U-shape kitchen layout
Three walls of cabinets wrap around the cook. This gives the most worktop and storage space of any layout and keeps everything within reach. It works best in larger rooms — in a small space it can feel cramped.
Island kitchen layout
An island adds a freestanding unit to the centre of an existing layout, usually L-shape or U-shape. It creates extra prep space, seating, and storage. You need at least 90–100 cm of clear aisle space on all sides, so room size matters.
Single-wall kitchen layout
All units run along one wall. It's the most compact option and suits studio flats or open-plan spaces where the kitchen is one zone among several. Storage is limited, so tall units and overhead cabinets are essential.
The Kitchen Work Triangle — And When to Ignore It
The kitchen work triangle connects three points: the sink, the stove, and the refrigerator. The idea is that keeping these close together — with each leg between 1.2 m and 2.7 m, according to commonly recommended planning guidance — reduces unnecessary walking while cooking.
It's a useful starting framework. But in open-plan kitchens, multi-cook households, or layouts with an island, a strict triangle often doesn't apply. A better approach for modern kitchens is to group tasks into zones — prep, cooking, cleaning, and storage — and make sure each zone has the worktop space and storage it needs nearby.
Use the triangle as a sense-check, not a rigid rule.
How to Measure Your Kitchen Before You Plan Anything
Accurate measurements entered into a kitchen floor plan tool prevent costly surprises. Measure before you plan — not after.
What to measure (step-by-step checklist)
- Overall room length and width (measure at floor level, both directions)
- Each wall individually — they're rarely identical
- Position of every door: width, swing direction, and distance from each corner
- Position of every window: width, height from floor, and distance from each corner
- Location of utility points: gas supply, electrical sockets, plumbing inlet and outlet, boiler
- Ceiling height (relevant for tall units and extraction ducts)
- Any alcoves, chimney breasts, or recesses
Use a tape measure and write every number down before you open any planning tool.
Common measuring mistakes to avoid
- Measuring only once. Always measure twice — discrepancies are common.
- Forgetting the door swing. A door that opens into a cabinet run is a problem you'll notice every day.
- Ignoring utility point positions. Moving a gas line or soil stack is expensive. Work around them where possible.
- Rounding up. Enter exact figures into your floor plan tool. Even 5 cm makes a difference in a tight run of cabinets.
Step-by-Step: How to Plan Your Kitchen Layout
This is the core process — from blank room to finished floor plan ready to share.
Step 1 — Draw your room outline to scale
Open your kitchen floor plan tool and draw the four walls using your measurements. With snap-to-grid drawing, walls lock to accurate increments automatically, so you don't need to be precise with the mouse — just enter the numbers.
Step 2 — Mark doors, windows, and utility points
Add every door (with its swing arc), every window, and mark where your gas, water, and electrical connections sit. These fixed points define what your layout can and can't do.
Step 3 — Choose your layout type
Decide on your configuration — galley, L-shape, U-shape, island, or single-wall — based on your room shape and the section above. This is the biggest decision. Everything else follows from it.
Step 4 — Place cabinets, appliances, and worktops
Drag base units, wall units, and appliances into position. Try your preferred layout first, then experiment. Moving a virtual cabinet on screen costs nothing. Moving a real one costs time and money.
Step 5 — Check clearances and traffic flow
Walk through the layout mentally. Is the aisle wide enough? Can the oven door open fully without hitting an island? Is there worktop space on both sides of the hob? Check the reference measurements in the next section.
Step 6 — Export and share with your fitter or contractor
Export your finished plan as a clean image — no measurements missing, no ambiguity. Send it to your fitter before the first conversation. You'll get more accurate quotes, fewer surprises, and a much smoother installation.
Key Measurements Every Kitchen Layout Needs
Use this as a quick reference when checking your plan:
| Element | Commonly Recommended Minimum |
|---|---|
| Main aisle width (one cook) | 90 cm |
| Main aisle width (two cooks) | 120 cm |
| Worktop depth (base units) | 60 cm |
| Overhead cabinet height from worktop | 45–50 cm |
| Overhead cabinet depth | 30–35 cm |
| Clearance beside hob | 30 cm each side |
| Dishwasher door clearance | 60 cm in front |
| Fridge door clearance | 60 cm in front |
These figures reflect widely used kitchen planning guidance. Your specific appliances may vary — always check the manufacturer's installation instructions for exact clearances.
How to Plan a Kitchen Layout Online — Free Tool Walkthrough
Free Room Planner is a browser-based kitchen floor plan tool that works on any device without sign-up, download, or payment. Here's what it lets you do:
- Draw walls to scale using snap-to-grid accuracy — walls lock to a 10 cm grid so your measurements are reliable.
- Add appliances and cabinets by dragging items from a library into your room outline.
- See live measurements update as you move and resize elements.
- Export a clean floor plan image to share with your contractor or fitter.
Ready to start? Open Free Room Planner now — no sign-up, no download, free. Draw your kitchen layout in minutes and export it straight to your fitter. Visit freeroomplanner.com.
If you're also planning other rooms, the same tool works as a bathroom renovation planner and covers living spaces too — useful if your kitchen renovation connects to a wider home project.
Sharing Your Kitchen Plan With a Contractor or Fitter
A rough sketch on paper leaves too much room for interpretation. A to-scale floor plan — with real dimensions, door positions, and appliance locations marked — tells your fitter exactly what you need before they set foot in your kitchen.
This means:
- Quotes that reflect the actual job, not an assumption
- Fewer back-and-forth questions before work starts
- Fewer surprises on installation day
Export your plan as an image and attach it to your initial message or quote request. It takes under a minute and changes the entire conversation.
For more on using visual plans throughout a renovation, see the full guide to how to plan a kitchen renovation.
Start Planning Your Kitchen Layout Today
Choose your layout type, measure your room carefully, and draw it to scale before you speak to anyone about cabinets or appliances. That sequence — plan first, buy second — is the single biggest difference between a kitchen renovation that goes smoothly and one that doesn't.
The free kitchen layout planner removes the biggest barrier: not knowing where to start. Open it in your browser, draw your room, and you'll have something concrete to work with in minutes — no sign-up, no download, no cost.
Want to compare other free planning tools? See best free kitchen planners compared for a full breakdown of what's available.
And if you're planning the wider home layout at the same time, the guide to best free house floor plan creators covers the tools that handle whole-home projects.
Frequently Asked Questions
Answers to the most common questions about planning a kitchen layout from scratch.
What is the best kitchen layout for a small kitchen?
A galley or single-wall layout works best in a small kitchen. Both keep everything within reach without requiring much floor space. A galley layout — two parallel runs of cabinets — is especially efficient in a narrow room. Avoid an island unless you have at least 90 cm of clear aisle space on all sides.
How do I measure my kitchen for a new layout?
Measure each wall individually at floor level, then record the position of every door (including swing direction), every window, and every utility point (gas, water, electricity). Write down ceiling height too. Measure everything twice before entering figures into any planning tool.
What is the kitchen work triangle?
The kitchen work triangle is a planning guide that connects the three most-used points in a kitchen — the sink, stove, and refrigerator. Keeping these points within a reasonable distance of each other reduces unnecessary movement while cooking. It's a useful starting point, but modern open-plan kitchens often work better with a zone-based approach instead.
Can I plan my kitchen layout online for free?
Yes. Free Room Planner is a browser-based kitchen floor plan tool that requires no sign-up, no download, and no payment. You draw your room to scale, add cabinets and appliances, and export a finished plan as an image to share with your fitter or contractor.
What clearances do I need around kitchen appliances?
Allow at least 60 cm of clear space in front of the oven, dishwasher, and refrigerator so doors can open fully. Leave at least 30 cm of worktop either side of the hob. Keep main aisles at least 90 cm wide for a single cook, or 120 cm if two people cook at the same time. These are commonly recommended minimums — check your appliance manufacturer's guidance for exact figures.
